حجم المنتج :
Ф48 - Ф3000
معيار:
جيجابايت/T23257-2009
سي/T0413-2002
DIN30670-91
يمكن/CSA-Z245.21-M92
管径 ماسورة التطوير التنظيمي | 壁厚 وزن | الطول (م) | |||||||||
منتجات جديدة الحد الأدنى للعائد القوة (ميغاباسكال) | |||||||||||
في. | مم | 245(ب) | 290 (X42) | 360 (X52) | 415 (X60) | 450 (X65) | 485 (X70) | 555 (X80) | 625 (X90) | 690 (X100) | |
16 | 406 | 6.0-37.0 | 6.0-34.0 | 6.0-31.0 | 6.0-29.0 | 6.0-28.0 | 6.0-27.0 | 6.0-26.0 | 6.0-25.0 | 6.0-24.0 | 6.0-13.5 |
18 | 457 | 6.0-40.0 | 6.0-37.0 | 6.0-34.0 | 6.0-31.0 | 6.0-30.0 | 6.0-29.0 | 6.0-28.0 | 6.0-27.0 | 6.0-25.0 | 6.0-13.5 |
20 | 508 | 6.0-43.0 | 6.0-40.0 | 6.0-36.0 | 6.0-34.0 | 6.0-32.0 | 6.0-31.0 | 6.0-29.0 | 6.0-29.0 | 6.0-27.0 | 6.0-13.5 |
22 | 559 | 6.0-45.0 | 6.0-42.0 | 6.0-38.0 | 6.0-36.0 | 6.0-34.0 | 6.0-33.0 | 6.0-31.0 | 6.0-30.0 | 6.0-28.0 | 6.0-13.5 |
24 | 610 | 6.0-48.0 | 6.0-44.0 | 6.0-40.0 | 6.0-38.0 | 6.0-36.0 | 6.0-35.0 | 6.0-33.0 | 6.0-32.0 | 6.0-30.0 | 6.0-13.5 |
26 | 660 | 6.0-50.0 | 6.0-46.0 | 6.0-42.0 | 6.0-40.0 | 6.0-38.0 | 6.0-37.0 | 6.0-34.0 | 6.0-33.0 | 6.0-31.0 | 6.0-13.5 |
28 | 711 | 6.0-52.0 | 6.0-48.0 | 6.0-44.0 | 6.0-41.0 | 6.0-40.0 | 6.0-38.0 | 6.0-36.0 | 6.0-34.0 | 6.0-33.0 | 6.0-13.5 |
30 | 762 | 7.0-55.0 | 7.0-50.0 | 7.0-46.0 | 7.0-43.0 | 7.0-41.0 | 7.0-40.0 | 7.0-37.0 | 7.0-36.0 | 7.0-34.0 | 6.0-13.5 |
32 | 813 | 7.0-57.0 | 7.0-52.0 | 7.0-48.0 | 7.0-44.0 | 7.0-43.0 | 7.0-41.0 | 7.0-39.0 | 7.0-38.0 | 7.0-36.0 | 6.0-13.5 |
34 | 864 | 7.0-59.0 | 7.0-54.0 | 7.0-49.0 | 7.0-46.0 | 7.0-44.0 | 7.0-43.0 | 7.0-40.0 | 7.0-39.0 | 7.0-37.0 | 6.0-13.5 |
36 | 914 | 8.0-61.0 | 8.0-56.0 | 8.0-51.0 | 8.0-48.0 | 8.0-46.0 | 8.0-44.0 | 8.0-42.0 | 8.0-40.0 | 8.0-38.0 | 6.0-13.5 |
38 | 965 | 8.0-63.0 | 8.0-580 | 8.0-52.0 | 8.0-49.0 | 8.0-47.0 | 8.0-46.0 | 8.0-43.0 | 8.0-41.0 | 8.0-39.0 | 6.0-13.5 |
40 | 1016 | 8.0-64.0 | 8.0-60.0 | 8.0-54.0 | 8.0-51.0 | 8.0-49.0 | 8.0-47.0 | 8.0-44.0 | 8.0-42.0 | 8.0-40.0 | 6.0-13.5 |
42 | 1067 | 8.0-66.0 | 8.0-61.0 | 8.0-56.0 | 8.0-52.0 | 8.0-50.0 | 8.0-48.0 | 8.0-45.0 | 8.0-43.0 | 8.0-41.0 | 6.0-13.5 |
44 | 1118 | 9.0-68.0 | 9.0-63.0 | 9.0-57.0 | 9.0-53.0 | 9.0-51.0 | 9.0-50.0 | 9.0-47.0 | 9.0-45.0 | 9.0-42.0 | 6.0-13.5 |
46 | 1168 | 9.0-70.0 | 9.0-64.0 | 9.0-58.0 | 9.0-55.0 | 9.0-53.0 | 9.0-51.0 | 9.0-48.0 | 9.0-46.0 | 9.0-44.0 | 6.0-13.5 |
48 | 1219 | 9.0-71.0 | 9.0-66.0 | 9.0-60.0 | 9.0-56.0 | 9.0-54.0 | 9.0-52.0 | 9.0-49.0 | 9.0-47.0 | 9.0-45.0 | 6.0-13.5 |
52 | 1321 | 9.0-73.0 | 9.0-67.0 | 9.0-61.0 | 9.0-57.0 | 9.0-55.0 | 9.0-53.0 | 9.0-50.0 | 9.0-48.0 | 9.0-46.0 | 6.0-13.5 |
56 | 1422 | 10.0-74.0 | 10.0-69.0 | 10.0-62.0 | 10.0-58.0 | 10.0-56.0 | 10.0-54.0 | 10.0-51.0 | 10.0-49.0 | 10.0-47.0 | 6.0-13.5 |
60 | 1524 | 10.0-75.0 | 10.0-70.0 | 10.0-63.0 | 10.0-59.0 | 10.0-57.0 | 10.0-55.0 | 10.0-52.0 | 10.0-50.0 | 10.0-48.0 | 6.0-13.5 |
64 | 1626 | 10.0-75.0 | 10.0-70.0 | 10.0-63.0 | 10.0-59.0 | 10.0-57.0 | 10.0-55.0 | 10.0-52.0 | 10.0-50.0 | 10.0-48.0 | 6.0-13.5 |
